Product Details

TJYD Series CNC Machine


CNC profiling / engraving machine

Countertop edge profiling machine

Full automatic stone processing  machine

CE certificate

Italy Motorized spindle

Taiwan Leadscrew, Japan servo

German leadscrew guide ways

Japanese Mitsubishi Electronics Technical


ModelTJYD-2015TJYD-2515TJYD-3015TJYD-3020TJYD-4020TJYD-5020
X axis stroke(mm)200025003000300040005000
Y axis stroke(mm)150015001500200020002000
Z axis stroke(mm)350350350350350350
wheel-holder spindle mator power (kw)111111111111
Rotation speed of the tool-holder spindle (r.p.m)1-100001-100001-100001-100001-100001-10000
Automatic  tool-changeIS0-40IS0-40IS0-40IS0-40IS0-40IS0-40
Tool-store (pcs)10r+10r10r+10r10r+10r10r+10r10r+10r10r+10r
Vacuum pump (m3/h)404040506065
Max thickness of machinable piece (mm)200200200200200200
Automatic centralized lubricationgrease
Push-button service with electronic handwheelEHDW-BA6S-IM
Water requirement(L/MIN)303535404550
Compressed air pressure (Bar)8888810
Max.total absorbed power (kw)131313131315
Overall dimension:L*W*H(m)4.2*2.7*2.74.7*2.7*2.75.2*2.7*2.75.2*3.2*2.76.2*3.2*2.77.2*3.2*2.7
Approximatic total machine weight (kg)300035004500500055006000



Our products are updated all the time, all the technical parameter and shape are basde on the real products.


Provide YD - 380 supercharger and Chinese CNC.
